U.S. Patent No. 8,856,780
TYPE 2 - WIRE CHART - 2 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
FORD
Taurus
STD key AT
13-15
CanH C251 Black 16 pin 03 Gray/Orange (DATA) OBDII connector G
CanL C251 Black 16 pin 11 Purple/Orange (DATA) OBDII connector G
Horn C2280B Black 52 pin 33 Purple/Green (-) BCM, driver side dash B
Driver Door Pin C2280C Black 26 pin 09 Green/Purple (OPEN) BCM, driver side dash B
Lock C2280C Black 26 pin 06 Blue/Green (-) BCM, driver side dash B
Unlock C2280C Black 26 pin 08 Yellow/Purple (-) BCM, driver side dash B
Trunk Release C2269 Black 06 pin 06 Brown (-) At trunk release switch on center console C
Parking Light C2280E Gray 10 pin 06 Yellow/Blue (+) BCM, driver side dash B
Auto Light C205 Gray 10 pin 04 Purple/Green or Purple (OPEN) Headlight switch A
Light Off C205 Gray 10 pin 06 White/Purple or White (-) Headlight switch A
Automotive Data Solutions Inc. © 2016 OEMFORSFO1BOLRSFO1EN
PAGE 9 OF 24
• 20160224
DOC.: #26841
