OMEM200 Installation Manual 2v10OMEM200 Installation Manual 2v10
20
2.12 Full Throttle Gearshift
Full throttle gearshift allows the driver to change gear without lifting the throttle by sending a signal to
the ECU when the gearshift is occurring so that the ECU can retard the ignition to reduce the power
output of the engine, allowing the gears to change.
On a ‘normal’ gearbox that requires clutch depression during the shift, a switch should be placed on the
clutch pedal to signal to the ECU that the shift is occurring. Gearboxes that shift without clutch depression
will require a switch on the lever to indicate the shift occurring.
Pin 10A (white / yellow) must be switched to earth to trigger the full throttle gearshift. Clutch switches
are available from Omex.
Earth
ECU FTG input
White / yellow
2.13 Alt Mode
To activate Alt Mode, a switch is required that supplies 12V to pin 11B (white / orange).
+12v
ECU Alt Mode input
White / orange
