The engine bay is a harsh environment for wiring harnesses with oil, water, solvents, high temperatures,
high vibration, and high electrical noise. The semi-assembled wiring harness is made from automotive
grade cable and the shielded cables are already made-up at the ECU connector to prevent electrical
noise problems.
The following should be noted when constructing the loom;
· The ECU should be mounted away from sources of extreme heat (such as exhaust), and
away from direct water spray.
· If the loom is to go through panels, grommets should be used.
· The looming material holding the wires in the loom should totally cover the wires to
prevent chaffing of the wire insulation.
· To minimize electrical interference, the sensors should be in a separately loomed section
of the harness to the injectors and ignition coils.
· The connector terminals should be either crimped with the correct tool or crimped and
soldered. Do not allow solder to go into the non-crimped section of the cable as this
makes the cable brittle.
· Any joins should if possible be covered by a mechanically stiff material such as heatshrink.
· Care should be taken if using Raychem DR-25 heatshrink or glue lined heatshrink as the
shrink temperature of these materials is high and it is possible to melt the cable insulation
when shrinking these materials.
· The loom should be tied to mounting points using cable ties or p-clips to limit the
additional stresses of the loom moving.
Please see the notes supplied with the harness.
OMEM200 Installation Manual 2v10
21
3.1 Semi Assembled Loom Construction
