Omni Cresco - Parameters Descriptions (H13-U2); H13 I2 T Thermal Parameter; H14 Braking Intensity Parameter; U1 Chopper Frequency Parameter

H13 I2T "thermal" (°C) 5 5 100 100 25 25 25
H14
Braking intensity cc from a
standing position: 1=1% …
100=100%
0 0 100 100 15 15 15
PARAMETERS CARRIAGE MOTOR
NAME
DESCRIPTION
MIN
MAX
DEF
N
M
N
M
N
M
U1
Chopper frequence :
1=1khz ... 20=20khz
1 1 20 20 4 4
U2
Maximum current from dc bus:
10=1A … 100 = 10A
10 10 100 100 40 40
U3
Overtemperature threshold :
30=30°C … 100=100°C
30 30 100 100 80 80
U4
Minimum voltage dc bus:
5 = 50V … 32=320V
0 0 32 32 25 25
U5
Maximum voltage dc bus:
16 = 160V … 50=500V
16 16 50 50 40 40
U6
Start voltage reduction low
speed (boost):
10=10hz … 80= 80hz
10 10 80 80 50 50
U7
voltage at 0 Hz (boost): 0 = 0%
… 40 = 40%
0 0 40 40 15 15
U8
Acceleration:
1=1dsec (0,1sec) …
100=100dsec (10sec)
1 1 100 100 5 5
U9
Deceleration:
1=1dsec (0,1sec) …
100=100dsec (10sec)
1 1 100 100 2 2
U10
Braking duration cc:
1=1dsec (0,1sec) …
100=100dsec (10sec)
1 1 100 100 10 10
U11
Braking intensity cc:
1=1% … 100=100%
1 1 100 100 10 10
U12
Speed inversion control , 0=std ,
1=reversed
0 0 1 1 0 0
U13
I2T "thermal" (°C)
5
5
100
100
25
25
U14
Braking intensity cc from a
standing position: 1=1% …
100=100%
0 0 100 100 15 15
CRESCO UCP REV10 17
