INVERTER SINAMICS V20
Par.
Access
level
Function Range
P100
1
50 / 60 Hz selection
= 0 Europe [kW], 50 Hz
= 1 North America [hp], 60 Hz
= 2 North America [kW], 60 Hz
0 - 2
P304
1
Rated motor voltage [V]
10 - 2000
P305
1
Rated motor current [A]
0.01 – 10000.00
P307
1
Rated motor power [kW/hp]
0.01 – 2000.00
P308 1
Rated motor power factor [cosϕ]
Visible only when P100 = 0 or 2
0.000 – 1.000
P310
1
Rated motor frequency [Hz]
12.00 – 599.00
P311
1
Rated motor speed [rpm]
0 - 40000
P1900
2
Select motor data identification
0 - 2
P1080
1
Minimum motor frequency
0.00 – 599.00
P1082
1
Maximium motor frequency
0.00 – 599.00
P1120
1
Ramp-up time [s]
0.00 – 650.00
P1121
1
Ramp-down time [s]
0.00 – 650.00
P700 1
Selection of command source
1 = factory default setting
2 = operator panel (keypad)
3 = terminal
5 = USS/MBUS on RS485
0 - 5
P701
2
Function of digital input 1
0 - 99
P1000
1
Selection of frequency setpoint
0 - 77
P2000
2
Reference frequency
1.00 – 650.00
P732
2
Function of digital output 2
-
R752
2
Actual analog input [V or mA]
-
P756 2
Type of analog input
0 = unipolar voltage input (0 to +10 V)
1 = unipolar voltage input with monitoring (0 to 10 V)
2 = unipolar current input (0 to 20 mA)
3 = unipolar current input with monitoring (0 to 20mA)
4 = bipolar voltage input (-10 V to +10 V)
0 - 4
P757
2
Value x1 of analog input scaling
-20 - 20
P758
2
Value y1 of analog input scaling [%]
-99999 - 99999
P759
2
Value x2 of analog input scaling
-20 - 20
P760
2
Value y2 of analog input scaling [%]
-99999 - 99999
P761
2
Width of analog input deadband
0 - 20
CRESCO UCP REV10 41
