Omnimount Play 25

11 of 19
888-45-280-W-01 rev.C • 11/12
6
A
B
C
D
75x75mm
100x100mm
100x200mm
200x200mm
200x100mm
100mm (3-15/16”)
75mm (2-15/16”)
100mm (3-15/16”)
75mm (2-15/16”)
100mm (3-15/16”)
200mm (7-7/8”)
200mm (7-7/8”)
200mm (7-7/8”)
100mm (3-15/16”)
200mm (7-7/8”)
VESA Adapter
Con gurations
TV/Monitor Hole
Pattern Sizes
Check size of
TV/Monitor hole
pattern
13
14
14
14
