Omnimount Play 25

14 of 19
888-45-280-W-01 rev.C • 11/12
OR
OR
100mm (3-15/16”)
200mm (7-7/8”)
200mm (7-7/8”)
200mm (7-7/8”)
100mm (3-15/16”)
200mm (7-7/8”)
B
C
D
M4x12
M5x12
M6x12
M4x12 M5x12 M6x12
Mount Type B, C, or D TV/Monitor to Arm
7
8
16
NOTE: To reduce
M8 holes for use
with M5 screws, or
if you have a model
with Samsung
holder rings, follow
the M8M5 KIT
instructions on the
next page.
