Omnimount Play 25 User Manual

6 of 19
888-45-280-W-01 rev.C • 11/12
2
3
4
a b c
Wood Stud Mount
c
b
d
Optional locking feature
(customer supplied lock)
2x
CAUTION: Make
sure the wall mount
bracket is level,
 ush and snug to
the wall surface.
DO NOT OVER-
TIGHTEN
THE BOLTS.
10
2.75”
Ø 3/16" (5mm)
13 mm
Stud Finder
Localizador de largueros de madera
Stud Finder
Auswahl von Montagematerial
Positiebepaler balken
Rilevatore di montanti
スタッド ファインダー
螺栓探测器
스터드 파인더
M8 x 80mm
