Procedure:
Step 1: Open the fuse holder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing. The fuse holder can be switched to one of two positions,
i.e. 230 V and 115 V.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
8. TECHNICAL SPECIFICATIONS
Power supply: 115/230 V AC, 50/60 Hz ~
Power consumption: 35 W
Inputs MIC 1-3: XLR/6.3 mm jack
Max. input level: -14 dB
Inputs LINE 1-3: stereo RCA
Max. input level: 24 dB
RETURN: 6.3 mm stereo jack
Outputs:
MASTER: 6.3 mm stereo jack
REC: stereo RCA
SEND: 6.3 mm jack
Tone control:
High: -12 dB to +12 dB/ 10 kHz
Bass: -12 dB to +12 dB/ 100 Hz
Distortion: 0.025 %
S/N ratio: 69 dB
Dimensions (WxDxH): 482 x 123 x 43 mm (19", 1 U)
Weight: 2.2 kg
Please note: Every information is subject to change without prior notice. 21.11.2008 ©
