7 CLEANING AND MAINTENANCE
Disconnect from mains before starting maintenance operation!
DANGER TO LIFE!
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.
8 TECHNICAL SPECIFICATIONS
Power supply: 2 x 15 V AC ~ (mixer)
230 V AC, 50 Hz ~ (power supply unit)
Power consumption: 60 W
Inputs:
Microphone 1,2 combined XLR (3-pin)/ 6.3 mm jack (bal.)
Minimum input voltage: 1 mV RMS
Line 1-8, Aux 1,2: stereo RCA
Minimum input voltage: 150 mV RMS
PHONO 1,2: stereo RCA
Minimum input voltage: 3 mV RMS
Outputs:
Master 1-3: stereo RCA, stereo XLR (3-pin)
Output voltage: 0.75 V/ 1.5 V RMS (switchable)
Record: stereo RCA
Output voltage: 0.75 V RMS
Headphones:
6.3 mm stereo jack (min. 8 Ω)
Tone control (microphone 1,2; zone 1-3):
5x High: -12 dB to +12 dB/ 10 kHz
5x Mid: -12 dB to +12 dB/ 1 kHz
5x Low: -12 dB to +12 dB/ 100 Hz
Talkover attenuation: -15 dB
S/N ratio: >65 dB
Frequency range: 20-20,000 Hz
Distortion: 0.03%
Dimensions (WxHxD): 483 x 117 x 90 mm (19", 2 U)
Weight: 2.5 kg
Please note: Every information is subject to change without prior notice. 04.06.2009 ©
