Omnitronic MP-60 - Technical Specifications

MP_SERIES_V_1_0.DOC
23/23
TECHNICAL SPECIFICATIONS
MP-60 MP-120 MP-180 MP-250
Power supply: 220-250 V AC,
50 Hz ~
220-250 V AC,
50 Hz ~
220-250 V AC, 50
Hz ~
220-250 V AC,
50 Hz ~
Output power: 60 W RMS 120 W RMS 180 W RMS 250 W RMS
Output type:
70 V, 100 V, 4-16 Ω 70 V, 100 V, 4-16 Ω 70 V, 100 V, 4-16 Ω 70 V, 100 V, 4-16 Ω
Output current:
70 V 1.2 A 2.5 A 3.6 A 5 A
100 V 0.8 A 1.8 A 2.5 A 3.5 A
Mic input: 5 mV, 600 Ohm 5 mV, 600 Ohm 5 mV, 600 Ohm 5 mV, 600 Ohm
Line input: 300 mV, 10 kOhm 300 mV, 10 kOhm 300 mV, 10 kOhm 300 mV, 10 kOhm
Frequency range: 80 Hz - 16 kHz 80 Hz - 16 kHz 80 Hz - 16 kHz 80 Hz - 16 kHz
Distortion: 0.5 % (1 kHz) 0.5 % (1 kHz) 0.5 % (1 kHz) 0.5 % (1 kHz)
S/N-ratio:
Aux: 85 dB 85 dB 85 dB 85 dB
Mic: 75 dB 75 dB 75 dB 75 dB
Dimensions: 483 x 300 x 92 mm 483 x 385 x 92 mm 483 x 385 x 92 mm 483 x 385 x 92 mm
Weight: 8 kg 12 kg 14 kg 16 kg
Please note: Every information is subject to change without prior notice. 08.06.2004 ©
