00072954.DOC, Version 1.0 20/20
8. PROBLEM CHART
PROBLEM CAUSE REMEDY
The power does not
turn on.
The power cable is not connected.
Connect the cable to a power outlet.
There is little or no
sound.
The input selector switch is in the
wrong position.
The connection cable was not
connected properly or not connected at all.
The terminal or plug is dirty.
The master level is too low.
Set the selector switch to the correct
signal source.
Connect the cable properly.
Clean and reconnect.
Increase the level with the master
control.
No function in MP3
player operation.
The USB dvice was not recognized.
The USB device is not compatible.
Remove the device and re-insert it.
Try using another device.
There is noise or
distortion.
The master level is too high.
The input level is too high.
Via the output meter, adjust the
master level to an optimum level with
the master control.
Via the output meter, adjust the
channel to an optimum level with the
gain control.
9. TECHNICAL SPECIFICATIONS
Power supply: 230 V AC, 50 Hz ~
via supplied power unit
Power consumption: 3 W
USB port: USB type A
Available storage media: USB devices up to 32 GB (FAT32)
Playback format: MP3, WAV
Inputs:
Line/phono: 2 x stereo RCA
DJ microphone: 6.3 mm jack, unbal.
Outputs:
Master: stereo RCA
Record: stereo RCA
Headphones:
6.3 mm stereo jack (≥32
Frequency range: 20-20000 Hz
S/N ratio: >75 dB
Distortion: <0.07 %
Dimensions (LxWxH): 180 x 140 x 65 mm
Weight: 1.2 kg
Please note: Every information is subject to change without prior notice. 19.02.2013 ©
