00029011.DOC, Version 1.2
16/16
6.5 Switching off
■ Set the POWER switch to OFF to turn off the transmitter. The display shortly indicates OFF and
goes off completely.
7 CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device except for the battery. Maintenance and service operations
are only to be carried out by authorized dealers.
In order to replace the battery please refer to "Inserting/exchanging batteries".
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.
8 TECHNICAL SPECIFICATIONS
Modulation: FM
Carrier frequency: UHF 863.100-864.900 MHz
RF power output: 10 mW
Microphone type: Condenser with omnidirectional pattern
Coverage: approx. 30 m (with line-of-sight)
Frequency response: 50 Hz-18 kHz (± 3 dB)
Frequency stability: ± 0.005 %
Power supply: 2 x 1.5 V mignon batteries (type AA)/
2 x 1.2 V rechargeable batteries (type AA)
Battery life: 13 hours (1.5 V mignon)
Rechargeable battery life: 8 hours (1300 mA)
Recharging time: approx. 4 hours (1300 mA rech. batteries)
Audio input: 3.5 mm stereo mini jack
Dimensions (LxWxH): 88 x 64 x 26 mm
Weight: 170 g
8.1 Channel configuration
Channel Radio Frequency Channel Radio Frequency
1 863.100 MHz 9 863.200 MHz
2 864.100 MHz 10 864.200 MHz
3 863.600 MHz 11 863.700 MHz
4 864.600 MHz 12 864.700 MHz
5 863.300 MHz 13 863.400 MHz
6 864.300 MHz 14 864.400 MHz
7 863.800 MHz 15 863.900 MHz
8 864.800 MHz 16 864.900 MHz
8.2 Accessory
OMNITRONIC W.A.M.S.-05 wireless PA system No. 13106985
OMNITRONIC Charging station for TM-105 No. 13107987
OMNITRONIC LS-105 Lavalier Microphone W05 No. 13056002
Belt for Bodypack receiver - transmitter No. 13063010
Battery Mignon(AA) 1.2V 2700mAh 4 pc No. 13108006
GP Powerbank TRAVEL incl.4x2700mAh AA Mig No. 13108060
Please note: Every information is subject to change without prior notice. 05.06.2009 ©
