OMP Hobby Edge 540 - Page 11

ElevatorAssembly
Ø HorizontalTailInstallation
2. Usesandpapertoroughentherootofcontrolarm.Tryto
insertitintothemountingslottoadjustthepositionat
first,thentakeitout,applygluetotheslotandtheroot
ofthecontrolarm,insertittotheslottosecureit.
3. Removethesecuredplateusedforfillingthehorizontal
tailslot,insertthehorizontaltailintofuselage,pleasetake
notethatitmustbefullyinsertedintothefuselage.
ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
4. Insertsecuredplatetofillthehorizontaltailslot,use502
gluingthegapallaroundthehorizontaltail.
