OMP Hobby Edge 540 - Page 13

RudderAssembly
Ø RudderInstallation
1. Carefullylocatetheslotwhichhasbeenmadeonthevertical
tail,lightlycutthroughthecoveringbutnotintothebalsa
sheeting.
2. Grindtherootofcontrolarms,tryitfirsttoinsertitintothe
slottoadjusttheposition,thentakeitout,applygluetothe
slotandtherootofthecontrolhorn,insertittotheslotto
secureit.
3. Remove4hingeswhichareinsertedintherudder.InjectAB
glueintotheholes,applyglueto4hingeswithappropriate
lengthfromitsbottom,theninsert4hingesintotherudder.
4. InjectABglueintotheholesinfuselage,applygluetothe
otherendofhingeswithappropriatelength,theninsertitinto
fuselage.
ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
