OMP Hobby Edge 540 - Page 14

RudderAssembly
6. Applygreaseorengineoilonalljointsbetweenrudderand
fuselage,andaroundthehinges,toavoidaffectingthe
sensitivityofrudderaftergluedried.
7. Tierudderwithmaskingtapewhileglueisstillwetto
preventloosening.
8. Makesuretheshaftisinthemiddleposition,andkeepthe
gapbetweenrudderandfuselagewithin1mm.
ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
9. Findthecenterpositiontosecurethetailwheelbracketto
rudder,drillahole,securethetailwheelbracketwithscrews.
(Noneedtofullyscrewedin)
10. Aftertheglueisdried,securetheservoarmandcontrol
armswithaballheadpullrod.
11. Makesuretheangleofservoandcontrolhornsis90° and
180°oblique,ensurerudderissymmetricaltothe2sidesof
fuselage.
