OMP Hobby Edge 540 - Page 15

GasEngineAssembly
Ø GasEngineInstallation
ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
1. Pastedouble‐sidedtapeonthebackoftheengineperforated
plate
2. Thefourlinesofthemountingplatearealignedwiththe
tensionlinesonthefirewall
3. Drillholeswitha5mmdrillbit(thespecificsizeofthedrillbit
dependsonthesizeofthescrewholeoftheengineormotor
mountingpostused)
4. Lightlytapwithascrewdrivertoremovethethrottleservo
mountingpositionandthefuselageairoutletwoodenboard.
5. Useautilityknifetoopentheairoutlet.
6. Useautilityknifetoopentheoutletoftheexhaustplate.
7. Aftertheguideplateisinstalledinplace,installtheexhaust
platewithscrews,asshowninthefigure
