Omron 3F88L-160 Connection Manual

Connection manual of XDesignerPlus external devices
7 / 12
4.2 Setting details of TOP main menu
- When hearing the sound while resetting the power, touch 1 upper point on LCD to move to“TOP
management main” screen..
- Set the driver interface settings of TOP according to the contents; Step1 → Step2.
(You can change the settings in Step2.if you click on “TOP COM 2/1 settings” in Step 1..)
Step 1. [ PLC Setup ] – Set the driver interface.
PLC Setup
PLC station number : 00
Communication interface
Time-out : 1000 [mSec]
settings
Delay time before transmission : 0 [mSec]
TOP COM 2/1 : RS – 232C , 9600 , 7 , 2 , EVEN
TOP COM 2/1 settings Communication check
Step 1–Reference.
Details
Contents
PLC station number.
[0~65535]
It is the station number of the other device. Select between [ 0 – 65535 ].
Time-out [ x1 mSec ]
Set the TOP’s wait time for response from external devices at [ 0 – 5000 ] x 1 mSec.
Delay time before
transmission [ x1 mSec ]
Set the TOP’s wait time between receiving the response from external devices – transmitting
the next command request at [0 - 5000] x 1 mSec.
TOP COM 2/1
It is the interface settings of TOP for external devices.
Step 2. [ PLC Setup ] >[ TOP COM2/COM1 settings ] – Set the serial parameters of the relevant port.
port settings
* Serial communication
COM 1 port
+ COM-1 Port
communication interface
- Parity bit : 9600 [BPS]
settings
- Data bit : 7 [BIT]
- Stop bit: 2 [BIT]
- Parity bit: EVEN [BIT]
- Signal level : RS – 232C
+ COM-2 Port
COM 2 port
- Parity bit : 9600 [BPS]
communication interface
- Data bit : 7 [BIT]
settings
- Stop bit: 2 [BIT]
- Parity bit: EVEN [BIT]
- Signal level : RS – 232C
Step 2-Reference.
Details
Contents
Parity bit
Select a serial communication speed between TOP – External devices
Data bit
Select a serial communication data bit between TOP – External devices.
Stop bit
Select a serial communication stop bit between TOP – External devices.
Parity bit
Select a method of checking serial communication parity bit between TOP – External devices.
Signal level
Select a serial communication method between TOP – External devices.
