Safety function selector switch
ON OFF
Wiring Example
M
X
+24V
SF2
3G3M1
24V
SF1
DIC
DOC
DO1
o
r
DO2
EDM
In the factory default state, operation is always enabled by the short-circuit bars as shown in the figure
above.
For details on connection with safety devices, refer to 7-6 Safety Function on page 7-69.
2 Design
2-59
M1 Series Standard Type User's Manual (I669)
2-3 Wiring
2
2-3-8 Safety Function
