Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
C37
Input Terminal [AI2]
Gain （AII Com-
mand）
0.00 to 400.00 %
100.00
Availa-
ble
%
page
7-38
page
7-123
C38
Input Terminal [AI2]
Filter (AII)
0.00 to 5.00 s
0.05
Availa-
ble
s
page
7-123
C39
Input Terminal [AI2]
Gain (AII Analog In-
put)
0.00 to 100.00 %
100.00
Availa-
ble
%
page
7-38
page
7-123
C40
Input Terminal [AI2]
Operation Selection
(AII)
0: 4 to 20mA Unipolar
1: 0 to 20mA Unipolar
10: 4 to 20mA Bipolar
11: 0 to 20mA Bipolar
0 -
-
page
7-38
page
7-123
C41
Input Terminal [AI2]
Offset （AIV
）
-5.0 to 5.0 %
0.0
Availa-
ble
%
page
7-38
page
7-123
C42
Input Terminal [AI2]
Gain (AIV Command)
0.00 to 400.00 %
100.00
Availa-
ble
%
page
7-38
page
7-123
C43
Input Terminal [AI2]
Filter (AIV)
0.00 to 5.00 s
0.05
Availa-
ble
s
page
7-123
C44
Input Terminal [AI2]
Gain (AIV Analog In-
put)
0.00 to 100.00 %
100.00
Availa-
ble
%
page
7-38
page
7-123
C45
Input Terminal [AI2]
Polarity Selection
(AIV)
0: Bipolar
1: Unipolar
1 - -
page
7-38
page
7-123
C50
Input Terminal [AI1,
AI2] Bias Analog Input
for 1st Frequency
Command
0.00 to 100.00 %
0.00
Availa-
ble
%
page
7-38
C53
Input Terminal [AI1,
AI2] Normal/Inverse
Operation for 1st Fre-
quency Command
0: Normal
1: Inverse
0
Availa-
ble
-
page
7-44
4 Parameter List
4-110
M1 Series Standard Type User's Manual (I669)
