Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
P16
1st Magnetic Satura-
tion Factor 1
0.0 to 300.0 %
92
Availa-
ble
%
page
6-65
P17
1st Magnetic Satura-
tion Factor 2
0.0 to 300.0 %
84.2
Availa-
ble
%
page
6-65
P18
1st Magnetic Satura-
tion Factor 3
0.0 to 300.0 %
70.5
Availa-
ble
%
page
6-65
P19
1st Magnetic Satura-
tion Factor 4
0.0 to 300.0 %
58.3
Availa-
ble
%
page
6-65
P20
1st Magnetic Satura-
tion Factor 5
0.0 to 300.0 %
46.1
Availa-
ble
%
page
6-65
P30
1st PM Motor Starting
Method
0: Pull-in by current
1: IPM motor type 1
2: SPM motor type
3: Pull-in by current for IPM
motor
4: IPM motor type 2
1 - -
page
6-6
page
6-22
P40 Do not use - - - - -
P41 Do not use - - - - -
P53
1st Motor %X Correc-
tion Factor
0 to 300 %
100
Availa-
ble
%
page
6-65
P55
1st Motor Torque Cur-
rent under Vector Con-
trol
0.00 to 500.0 A
16.71 - A
page
6-6
P56
1st Induced Voltage
Factor under Vector
Control
50 to 100 %
95 - %
page
6-6
P57 Do not use - - - - -
P60
1st PM Motor Arma-
ture Resistance
0.000 to 50.00 ohm
0.253 - ohm
page
6-65
4 Parameter List
4-114
M1 Series Standard Type User's Manual (I669)
