Parameter No.
Parameter name
1st control 2nd control
H068 A040 Slip Compensation Operating Conditions Selection
H080 A041 Output current fluctuation damping gain for motor
F043 E146 Overload Protect Function Selection
F044 E147 Overload Protect Level
E037 E056 Overload Early Warning Detection Level
E038 E055 Overload Early Warning Detection Timer
E039 A061
Display Coefficient 1 for Transport Time / Auxiliary Display Coefficient 1
for Speed Monitor
E050 A060 Display coefficient for speed monitor
E112 E113 Torque Boost Function Selection
F009 A005 Manual Torque Boost Voltage
E122 E123 AVR Function Selection
C053 C054
Input Terminal [AI1, AI2] Normal/Inverse Operation for Frequency Com-
mand
P001 A015 Number of motor poles
P002 A016 Motor capacity
P003 A017 Motor Rated Current
P004 A018 Auto Tuning　Function Selection
P005 A019 Online Tuning Function Selection
P006 A020 Motor Armature Resistance
P007 A021 Motor Parameter %R1
P008 A022 Motor Parameter %X
P053 A053 Motor %X Correction Factor
P009 A023 Slip Compensation Gain for Driving
P010 A024 Slip Compensation Response Time
P011 A025 Slip Compensation Gain for Braking
P012 A026 Rated Slip Frequency
P013 A027 Iron Loss Factor 1
P016 A030 Magnetic Saturation Factor 1
P017 A031 Magnetic Saturation Factor 2
P018 A032 Magnetic Saturation Factor 3
P019 A033 Magnetic Saturation Factor 4
P020 A034 Magnetic Saturation Factor 5
P055 A055 Torque Current for Vector Control
P056 A056 Induced Voltage Factor for Vector Control
• The following parameters are enabled only when 1st control is selected. When 2nd control is select-
ed, this control operates by setting the following parameters.
Parameter No. Parameter name
F018 Input Terminal [AI1, AI2] Bias for 1st Frequency Command
C050 Input Terminal [AI1, AI2] Bias Analog Input for 1st Frequency Command
H195 DC Injection Braking Startup Time
H078 1st Motor Maintenance Interval
H079 1st Preset Startup Count for Motor Maintenance
M081 1st Remaining Time before the Next Motor Maintenance
M085 1st Remaining Startup Times before the Next Motor Maintenance
5 Basic Settings
5-54
M1 Series Standard Type User's Manual (I669)
