D
D1
6
110 (W)
96.5
2xϕ5.2
130 (H)
118
7
Power
supply
Model W [mm] H [mm] D [mm] D1 [mm]
Single-
phase 200
V
3G3M1-AB015
110 130
166
58
Three-
phase 200
V
3G3M1-A2015
3G3M1-A2022 156
Three-
phase 400
V
3G3M1-A4004 132 38
3G3M1-A4007
3G3M1-A4015
3G3M1-A4022
156 58
1 Overview
1-19
M1 Series Standard Type User's Manual (I669)
1-3 Specifications
1
1-3-2 External Dimensions
