7-9-24
Overload Stop Function
This function is used to detect the load condition, and if the state exceeding the Overload Stop Detec-
tion Level (J64) continues for the Overload Stop Detection T
imer (J67) or longer, stop operation is per-
formed by the overload stop function.
Select the stop operation at Overload Stop Mode Selection (J65). If “0: Disable” is selected, the over-
load stop function is disabled.
The overload stop function is enabled only for the 1st control.
Select the operation to detect at Overload Stop Operation Mode (J66).
Select the item to detect at Overload Stop Item Selection (J63).
Parameter No. Function name Data Default data Unit
J65
Overload Stop Mode
Selection
0: Disable
1: Deceleration stop
2: Free run stop
3: Torque limit operation (Deceleration)
0 -
J63
Overload Stop Item
Selection
0: Torque
1: Current
0 -
J64
Overload Stop Detec-
tion Level
20 to 200
The data is interpreted as the rated out-
put current of the inverter for 100%.
100
%
J66
Overload Stop Opera-
tion Mode
0: During constant speed running and
deceleration
1: During constant speed running
2: Anytime
0 -
J67
Overload Stop Detec-
tion T
imer
0.00 to 600.00 s 0.00 s
J90
Overload Stop Func-
tion P gain
0.000 to 2.000; 999
0.000 to 2.000 times
999: 0.050 times
999
time
J91
Overload Stop Func-
tion Integral time
0.001 to 9.999; 999
0.001 to 9.999s
999: 0.025s
999 s
J92
Overload Stop Func-
tion Current level
50.0% to 150.0% 100 %
E01 to E05, E98,
E99
Input Terminal [DI1] to
[DI7] Function Selec-
tion
46：OLS (Enable overload stop) - -
Overload Stop Enabled OLS
Turning the OLS terminal ON enables overload stop and turning the terminal OFF disables overload
stop.
Note that if overload stop is disabled by turning OFF the OLS terminal in a state when the inverter has
stopped due to overload stop, the inverter will restart.
Overload Stop Mode Selection (J65)
• Select the stop operation at Overload Stop Mode Selection (J65). If “0: Disable” is selected, the
overload stop function is disabled.
7 Other Functions
7-153
M1 Series Standard Type User's Manual (I669)
7-9 Other Operation Functions
7
7-9-24 Overload Stop Function
