Parameter No. Function name Data Default data Unit
E01 to E05, E98,
E99
Input Terminal [DI1] to
[DI7] Function Selec-
tion
25:U-DI (Universal DI) 0 -
S06 Operation command
0000 to FFFF hex
Bit15: RST
Bit14: DI7
Bit13: DI6
Bit6: DI5
Bit5: DI4
Bit4: DI3
Bit3: DI2
Bit2: DI1
Bit1: REV
Bit0: FWD
- -
W40 Input Terminal Monitor
0000 to FFFF hex
Bit12: EN2
Bit1
1: EN1
Bit6: DI5
Bit5: DI4
Bit4: DI3
Bit3: DI2
Bit2: DI1
Bit1: DI7
Bit0: DI6
- -
Universal DO
When “27: OPO (Option board output)” is allocated to the output terminal, output is performed from the
corresponding output terminal when data is written to the Communication Data T
erminal [DO] (S07)
from communication regardless of inverter operation.
Parameter No. Function name Data Default data Unit
S07
Communication Data
Terminal [DO]
Bit8: RO
Bit1: DO2
Bit0: DO1
0 -
Universal AO
When “10: Universal AO” is allocated to the analog output terminal, output is performed from the ana-
log terminal when data is written to the Communication Data Terminal [AO] (S12) from communication.
Full scale is assumed for a numeric value of 20000.
Parameter No. Function name Data Default data Unit
F31
Output Terminal [AO]
Function Selection
10: Universal AO
0 -
S12
Communication Data
T
erminal [AO]
-32,768 to 32,767
(-20,000 = -100%, 20,000 = 100%)
0 -
7 Other Functions
7-156
M1 Series Standard Type User's Manual (I669)
