Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size
[mm2]
DC reactor connection (P1,
P(+))
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C
3G3M1-A2002 3G3M1-A2001 0.2 2.0 2.0 2.0 1.1
- 3G3M1-A2002 0.4 2.0 2.0 2.0 2.0
3G3M1-A2004 - 2.0 2.0 2.0 2.0
- 3G3M1-A2004 0.75 2.0 2.0 2.0 3.7
3G3M1-A2007 - 2.0 2.0 2.0 3.7
- 3G3M1-A2007 1.1 2.0 2.0 2.0 5.3
3G3M1-A2015 - 1.5 2.0 2.0 2.0 7.0
- 3G3M1-A2015 2.2 2.0 2.0 2.0 10.2
3G3M1-A2022 - 2.0 2.0 2.0 10.2
- 3G3M1-A2022 3 2.0 2.0 2.0 14.3
3G3M1-A2037 - 3.7 2.0 2.0 2.0 17.1
- 3G3M1-A2037 5.5 3.5 2.0 2.0 24.4
3G3M1-A2055 - 3.5 2.0 2.0 25.8
3G3M1-A2075 3G3M1-A2055 7.5 5.5 3.5 3.5 35.3
3G3M1-A2110 3G3M1-A2075 11 14.0 5.5 5.5 51.7
3G3M1-A2150 3G3M1-A2110 15 14.0 14.0 8.0 70.5
3G3M1-A2185 3G3M1-A2150 18.5 22.0 14.0 14.0 87.0
- 3G3M1-A2185 22
38.0
*1
22.0 14.0 103.4
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Brake resistance connection (P(+), DB)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-A2001 - 0.1 2.0 2.0 2.0 0.3 - - - -
3G3M1-A2002 3G3M1-A2001 0.2 2.0 2.0 2.0 0.4 2.0 2.0 2.0 0.3
- 3G3M1-A2002 0.4 - - - - 2.0 2.0 2.0 0.4
3G3M1-A2004 - 2.0 2.0 2.0 0.5 - - - -
- 3G3M1-A2004 0.75 - - - - 2.0 2.0 2.0 0.6
3G3M1-A2007 - 2.0 2.0 2.0 0.7 - - - -
- 3G3M1-A2007 1.1 - - - - 2.0 2.0 2.0 0.8
3G3M1-A2015 - 1.5 2.0 2.0 2.0 1.4 - - - -
- 3G3M1-A2015 2.2 - - - - 2.0 2.0 2.0 1.5
3G3M1-A2022 - 2.0 2.0 2.0 1.7 - - - -
- 3G3M1-A2022 3 - - - - 2.0 2.0 2.0 1.7
3G3M1-A2037 - 3.7 2.0 2.0 2.0 2.4 - - - -
2 Design
2-30
M1 Series Standard Type User's Manual (I669)
