Omron 3G3M1-A4030-ECT User Manual

Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Brake resistance connection (P(+), DB)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
- 3G3M1-A2037 5.5 - - - - 2.0 2.0 2.0 2.5
3G3M1-A2055 - 2.0 2.0 2.0 3.8 - - - -
3G3M1-A2075 3G3M1-A2055 7.5 2.0 2.0 2.0 5.0 2.0 2.0 2.0 3.8
3G3M1-A2110 3G3M1-A2075 11 2.0 2.0 2.0 7.5 2.0 2.0 2.0 5.3
3G3M1-A2150 3G3M1-A2110 15 2.0 2.0 2.0 9.4 2.0 2.0 2.0 7.5
3G3M1-A2185 3G3M1-A2150 18.5 2.0 2.0 2.0 12.7 2.0 2.0 2.0 9.0
- 3G3M1-A2185 22 2.0 2.0 2.0 13.8 2.0 2.0 2.0 12.0
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire
size [mm2]
Inverter ground (G)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
60°C 75°C 90°C
3G3M1-A2001 - 0.1 2.0 2.0 2.0
3G3M1-A2002 3G3M1-A2001 0.2 2.0 2.0 2.0
- 3G3M1-A2002 0.4 2.0 2.0 2.0
3G3M1-A2004 - 2.0 2.0 2.0
- 3G3M1-A2004 0.75 2.0 2.0 2.0
3G3M1-A2007 - 2.0 2.0 2.0
- 3G3M1-A2007 1.1 2.0 2.0 2.0
3G3M1-A2015 - 1.5 2.0 2.0 2.0
- 3G3M1-A2015 2.2 2.0 2.0 2.0
3G3M1-A2022 - 2.0 2.0 2.0
- 3G3M1-A2022 3 2.0 2.0 2.0
3G3M1-A2037 - 3.7 2.0 2.0 2.0
- 3G3M1-A2037 5.5 3.5 3.5 3.5
3G3M1-A2055 - 3.5 3.5 3.5
3G3M1-A2075 3G3M1-A2055 7.5 5.5 5.5 5.5
3G3M1-A2110 3G3M1-A2075 11 5.5 5.5 5.5
3G3M1-A2150 3G3M1-A2110 15 5.5 5.5 5.5
3G3M1-A2220 3G3M1-A2150 18.5 8.0 8.0 8.0
- 3G3M1-A2185 22 8.0 8.0 8.0
2 Design
2-31
M1 Series Standard Type User's Manual (I669)
2-3 Wiring
2
2-3-4 Wiring for Main Circuit Terminals
