Three-phase 400-V class (Panel internal temperature 40°C or less)
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Main power supply input (L1/R, L2/S, L3/T)
When DC reactor (DCR) is
used
Without DC reactor (DCR)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-A4004 - 0.4 2.0 2.0 2.0 0.9 2.0 2.0 2.0 1.7
- 3G3M1-A4004 0.75 2.0 2.0 2.0 1.5 2.0 2.0 2.0 2.7
3G3M1-A4007 - 2.0 2.0 2.0 1.6 2.0 2.0 2.0 3.1
- 3G3M1-A4007 1.1 2.0 2.0 2.0 2.1 2.0 2.0 2.0 3.9
3G3M1-A4015 - 1.5 2.0 2.0 2.0 3.0 2.0 2.0 2.0 5.9
- 3G3M1-A4015 2.2 2.0 2.0 2.0 4.2 2.0 2.0 2.0 7.3
3G3M1-A4022 - 2.0 2.0 2.0 4.4 2.0 2.0 2.0 8.2
- 3G3M1-A4022 3 2.0 2.0 2.0 5.8 2.0 2.0 2.0 11.3
3G3M1-A4030 -
- 3G3M1-A4030 3.7 2.0 2.0 2.0 7.3 2.0 2.0 2.0 13.0
3G3M1-A4040 -
- 3G3M1-A4040 5.5 2.0 2.0 2.0 10.1 2.0 2.0 2.0 16.8
3G3M1-A4055 - 2.0 2.0 2.0 10.6 2.0 2.0 2.0 17.3
3G3M1-A4075 3G3M1-A4055 7.5 2.0 2.0 2.0 14.4 3.5 2.0 2.0 23.2
3G3M1-A4110 3G3M1-A4075 11 2.0 2.0 2.0 21.1 5.5 3.5 2.0 33.0
3G3M1-A4150 3G3M1-A4110 15 3.5 2.0 2.0 28.8 8.0 5.5 3.5 43.8
3G3M1-A4185 3G3M1-A4150 18.5 5.5 3.5 3.5 35.5 14.0 8.0 5.5 52.3
3G3M1-A4220 3G3M1-A4185 22 8.0 5.5 3.5 42.2 14.0 8.0 5.5 60.6
- 3G3M1-A4220 30 14.0 8.0 5.5 57.0 22.0 14.0 8.0 77.9
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Inverter output (U, V, W)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-A4004 - 0.4 2.0 2.0 2.0 1.8 - - - -
- 3G3M1-A4004 0.75 - - - - 2.0 2.0 2.0 2.1
3G3M1-A4007 - 2.0 2.0 2.0 3.4 - - - -
- 3G3M1-A4007 1.1 - - - - 2.0 2.0 2.0 4.1
3G3M1-A4015 - 1.5 2.0 2.0 2.0 4.8 - - - -
- 3G3M1-A4015 2.2 - - - - 2.0 2.0 2.0 5.5
3G3M1-A4022 - 2.0 2.0 2.0 5.5 - - - -
- 3G3M1-A4022 3 - - - - 2.0 2.0 2.0 6.9
3G3M1-A4030 -
- 3G3M1-A4030 3.7 2.0 2.0 2.0 9.2 - - - -
3G3M1-A4040 -
2 Design
2-32
M1 Series Standard Type User's Manual (I669)
