Datenblatt
Zeitrelais H3DT
H3DT
H3DT-A
15
Nomenclature
Dimensions (Unit: mm)
Timers
Track Mounting Products (Sold Separately)
Refer to page 29 for details.
Options (Order Separately)
Front Cover
Refer to page 29 for details.
Time range switch *
* If the switch is left between settings, proper operation may not be possible.
Make sure that the switch is set properly.
Note: The default settings are for 0.1 s.
Front View
Output indicator (orange)
(Lit while Timer gives output.)
Main dial
(for setting the time)
Operation/power indicator (green)
(Flashes while Timer is operating.
Lit when Timer is stopped.)
H3DT-A2
Time range switch *
* If the switch is left between settings, proper operation may not be possible.
Make sure that the switch is set properly.
Note: The default settings are for 0.1 s.
Front View
Output indicator (orange)
(Lit while Timer gives output.)
Operation/power indicator (green)
(Flashes while Timer is operating.
Lit when Timer is stopped.)
Main dial
(for setting the time)
H3DT-A1
17.5 17.5
90
90
86
5
H3DT-A2 H3DT-A1
100
H3DT-A
