LR
*
* CSA conformance evaluation by UL.
Ordering Information
List of Models
Model Structure
* Certification is pending for DNV GL.
Specifications
Time Ranges
Ratings
*1. When using a 24-VDC power supply voltage, there will be an inrush current of approximately 0.5 A. Allow for this inrush current when turning
ON and OFF the power supply to the Timer with device with a solid-state output, such as a sensor.
*2. DC ripple: 20% max.
Operating modes Supply voltage Control output H3DT-F
Flicker OFF start/flicker ON start 24 to 240 VAC/DC Contact output: SPDT Model H3DK-F
Model Operating modes Terminal block Output type Mounting method Safety standards
H3DT-F Flicker OFF start/flicker ON start 6 terminals Relay, SPDT DIN Track mounting
cULus
(UL508 CSA C22.2 No. 14)
CCC
LR
DNV GL *
EN 61812-1
IEC 60664-1 4 kV/2
Time range setting 0.1 s 1 s 10 s 1 min 10 min 1 h 10 h 100 h
Set time range 0.1 to 1.2 s 1 to 12 s 10 to 120 s 1 to 12 min 10 to 120 min 1 to 12 h 10 to 120 h 100 to 1,200 h
Scale numbers 12
Power supply voltage *1 24 to 240 VAC/DC, 50/60 Hz *2
Allowable voltage fluctuation range 85% to 110% of rated voltage
Power reset Minimum power-OFF time: 0.1 s
Reset voltage 10% of rated voltage
Power consumption H3DT-F At 240 VAC: 1.9VA max., at 240 VDC: 0.6W max., at 24 VDC: 0.3W max.
Rated Insulation Voltage 250 VAC
Control output
Contact output: 5 A at 250 VAC with resistive load (cos = 1),
5 A at 30 VDC
with resistive load,
0.15 A max. at 125 VDC with resistive load,
0.1 A max. at 125 VDC with L/R of 7 ms.
The minimum applicable load is 10 mA at 5 VDC (P reference value).
Contact materials : Ag-alloy
(Recommended fuse: BLN5 (Littelfuse) or 0216005MXEP)
Ambient operating temperature 20 to 60C (with no icing)
Storage temperature 40 to 70C (with no icing)
Surrounding air operating humidity 25% to 85%
