Zeitrelais H3DT
H3DT
1
New Product
Solid-state Timers
H3DT
DIN 17.5-mm-wide Slim Timers with
Push-in Plus Technology for
In-panel Applications
• Helps save space and reduces work in control panels.
• Slim Timers (17.5-mm width) with two sets of
contacts: One of the slimmest Timers worldwide. *1
• Reduces power consumption (active power) by up to 60%
to help reduce heat generation in control panels. *2
• Certified for maritime standards (LR/DNV GL). *3
• RoHS compliant
*1. According to OMRON investigation in October 2015.
*2. Based on OMRON comparison (excluding the H3DT-H).
*3. Certification is pending for DNV GL.
LR
＊
＊ CSA conformance evaluation by UL.
For the most recent information on models that have been
certified for safety standards, refer to your OMRON website.
Model Number Structure
The Entire H3DT Series
Model Number Legend
H3DT Series
H3DT-N/-L Multi-range,
Multi-mode Timers
■Standard Eight-mode Timers
H3DT-N
● Operating Modes
A2: ON Delay (Power ON Delay)
B3: Flicker OFF Start (Power ON Start)
B4: Flicker ON Start (Power ON Start)
D: Signal OFF Delay
E2: Interval (Power ON Start)
E3: Signal OFF Interval
F2: Cumulative (ON Delay)
F3: Cumulative (Interval)
● Operating Modes
Flicker-OFF Start/
Flicker-ON Start
● Operating Modes
Star-delta Timer
● Operating Modes
Power OFF-delay Timer
● Operating Modes
Power ON-delay Timer
H3DT-A
Power ON-delay
Timers
H3DT-F
Twin Timers
H3DT-G
Star-delta Timers
H3DT-H
Power OFF-delay
Timers
■Expansion Eight-mode Timers
H3DT-L
● Operating Modes
A: ON Delay (Signal ON Delay)
B: Flicker OFF Start (Signal Start)
B2: Flicker ON Start (Signal Start)
C: Signal ON/OFF Delay
E: Interval (Signal Start)
G: Signal ON/OFF Delay
J: One-shot Output (Signal Start)
J2: One-shot Output (Power ON Start)
P.2
P.17 P.21P.12
P.25
H3DT - @@@@
1234
1. Type
2. Control Output *
* N-, L- and A-type models only.
3. Supply Voltage
* H-type models only.
4. Time Ranges *
* H-type models only.
Symbol Meaning
N
Standard Eight-mode
Timer
L
Expansion Eight-mode
Timer
A Power ON-delay Timer
F Twin Timer
G Star-delta Timer
H Power OFF-delay Timer
Symbol Meaning
1 SPDT
2DPDT
Symbol Meaning
Blank 24 to 240 VAC/DC
B * 24 to 48 VAC/DC
C * 100 to 120 VAC
D * 200 to 240 VAC
Symbol Meaning
S 0.1 to 1.2 s or 1 to 12 s
L 1 to 12 s or 10 to 120 s
