4.2 Taking a Measurement
Refer to sub-section 3.1 to start a measurement. Open the app on your
smart device and follow the instructions.
• Make sure that your monitor is within 16 ft. (5 m) of your smart device.
Transferring Data Automatically/Manually
• The readings will be transferred to your smart device within 1 hour after
taking a measurement.
• To transfer the readings manually, press the button.
4.3 Disabling/Enabling Bluetooth
• This product emits radio frequencies (RF) in the 2.4 GHz band. DO NOT
use this product in locations where RF is restricted, such as on an
aircraft or in hospitals. Turn off the Bluetooth feature in this monitor and
remove batteries when in RF restricted areas. For further information on
potential restrictions refer to documentation on the Bluetooth usage by
the FCC/ISED.
Bluetooth is enabled as default.
1. When your monitor is off, press and hold the
button for more than 10 seconds.
“oFF” flashes 3 times.
2. Press the [START/STOP] button to turn your monitor off.
•To enable the Bluetooth, press and hold the button for more than
2 seconds. “on” appears on the display.
•Your monitor automatically turns off 2 minutes after the completion.
•When Bluetooth is disabled, the “ ” symbol appears.
Your monitor automatically stores up to 80 readings.
• This monitor can be used by multiple users. When you use memory
function with other users, track (or manage) your own readings
appropriately.
5.1 Viewing the Readings Stored in Memory
1. Press the button.
The Memory number appears for 1.5 seconds before the pulse rate is
displayed. The most recent reading stored in the memory will be
numbered as “1”.
•If the reading is high (refer to sub-section 1.3), the
“ ” symbol appears.
•If there are no readings stored in the memory, the
screen to the right is displayed.
•If the memory is full, new readings will replace the
old readings, starting with the oldest reading.
2. Press the or button repeatedly to scroll through the
previous readings stored in the memory.
: To view the older readings
: To view the more recent readings
5.2 Viewing the Average Reading
Your monitor can calculate an average reading based on the latest 2 or 3
readings taken within the most recent 10 minute timeframe.
• Set your monitor to the correct date and time before taking a
measurement to view the average readings.
1. When your monitor is off, press and hold the
button for more than 2 seconds.
The “ ” symbol flashes.
•If there are only 2 readings in the memory for that
period, the average will be based on these 2
readings.
•If the average reading is high (refer to sub-section
1.3), the “ ” symbol appears.
5. Using Memory Function
Alternating
date/time
display
6.1 Deleting All Readings Stored in Memory
1. Press the button.
After a memory number appears, the latest reading will appear.
2. While holding the button
down, press and hold the
[START/STOP] button for
more than 3 seconds.
The display to the right flashes.
3. While holding the button
down again, press and hold
the [START/STOP] button for
more than 3 seconds.
The display stops flashing, then
all readings are deleted.
4. Press the [START/STOP] button to turn your monitor off.
•All readings will be deleted. You cannot partially delete the readings
stored in the memory.
•Your monitor automatically turns off after 2 minutes.
6.2 Restoring Your Monitor to the Default Settings
To delete all the information stored in your monitor, follow the instructions
below. Make sure that your monitor is turned off.
1. While holding the
button down, press
and hold the [START/
STOP] button for more
than 3 seconds.
The display to the right
flashes.
2. While holding the
button down again,
press and hold the
[START/STOP] button for
more than 3 seconds.
The display stops flashing,
then your monitor is restored
to the default settings.
3. Press the [START/STOP] button to turn your monitor off.
•After the completion, the year flashes on the display. Refer to sub-
section 2.2 to set the date and time manually, or refer to sub-section
4.1 to pair your monitor to set the date and time automatically.
•Reverting to the default setting of your monitor does not delete the
information in the app.
If any of the below problems occur during measurement, check to make
sure that no other electrical device is within 12 inches (30 cm). If the
problem persists, refer to the table below.
6. Other Settings
7. Error Messages and Troubleshooting
Display/Problem Possible Cause Solution
appears or the arm
cuff does not inflate.
Air plug is not completely
plugged into the monitor.
Insert the air plug
securely. Refer to sub-
section 2.4.
The arm cuff is not
applied correctly.
Apply the arm cuff
correctly, then take
another measurement.
Refer to sub-section 2.4.
Air is leaking from the
arm cuff.
Replace the arm cuff
with a new one. Refer to
section 9.
appears or a
measurement
cannot be complete
after the arm cuff
inflates.
You move or talk during
a measurement and the
arm cuff does not inflate
sufficiently.
Remain still and do not
talk during a
measurement. If “E2”
appears repeatedly,
inflate the arm cuff
manually until the
systolic pressure is 30 to
40 mmHg above your
previous readings. Refer
to sub-section 3.1.
The systolic pressure is
above 210 mmHg and a
measurement cannot be
taken.
Inflate the arm cuff
manually until the
systolic pressure is 30 to
40 mmHg above your
previous readings. Refer
to sub-section 3.1.
appears
The arm cuff is inflated
exceeding the maximum
allowable pressure.
Do not touch the arm cuff
and/or bend the air tube
while taking a
measurement.
If inflating the arm cuff
manually, refer to the
end of sub-section 3.1.
appears
You move or talk during
a measurement.
Vibrations disrupt a
measurement.
Remain still and do not
talk during a
measurement.
appears
The pulse rate is not
detected correctly.
Apply the arm cuff
correctly, then take
another measurement.
Refer to sub-section 2.4.
Remain still and sit
correctly during a
measurement.
If the “ ” symbol
continues to appear, we
recommend you to
consult with your
physician.
/
appears
does not flash during
a measurement
appears
The monitor has
malfunctioned.
Press the [START/
STOP] button again. If
“Er” still appears, contact
customer service. Refer
to section 12.
appears
The monitor cannot
connect to a smart
device or transmit data
correctly.
Follow the instructions
shown in the “OMRON
connect US/CAN” app. If
the “Err” symbol still
appears after checking
the app, contact
customer service. Refer
to section 12.
flashes
The monitor is waiting for
pairing with the smart
device.
Refer to sub-section 4.1
for pairing your monitor
with your smart device,
or press the [START/
STOP] button to cancel
pairing and turn your
monitor off.
flashes
The monitor is ready to
transfer your readings to
the smart device.
Open the “OMRON
connect US/CAN” app to
transfer your readings.
flashes
There are more than 64
readings in memory to
be transferred.
Pair or transfer your
readings to the “OMRON
connect US/CAN” app so
you can keep them in
memory in the app, and
this error symbol
disappears.
The date and time is not
set.
appears
There are 80 readings in
memory to be
transferred.
flashes
Batteries are low.
Replacing all 4 batteries
with new ones is
recommended. Refer to
sub-section 2.1.
appears or the
monitor is turned off
unexpectedly during
a measurement.
Batteries are depleted.
Immediately replace all 4
batteries with new ones.
Refer to sub-section 2.1.
Nothing appears on
the display of the
monitor.
Batteries are depleted.
Battery polarities are not
properly aligned.
Check the battery
installation for proper
placement. Refer to sub-
section 2.1.
Readings appear too
high or too low.
Blood pressure varies constantly. Many factors
including stress, time of day, and/or how you apply
the arm cuff, may affect your blood pressure.
Review sub-sections 2.3 - 2.5 and section 3.
Any other
communication
issue occurs.
Follow the instructions shown in the smart device,
or visit the “Support” section in the “OMRON
connect US/CAN” app for further help. If the
problem still persists, contact customer service.
Refer to section 12.
Any other problems
occur.
Press the [START/STOP] button to turn the monitor
off, then press it again to take a measurement. If
the problem continues, remove all batteries and
wait for 30 seconds. Then re-install batteries.
If the problem still persists, contact customer
service. Refer to section 12.
Display/Problem Possible Cause Solution
8.1 Maintenance
To protect your monitor from damage, follow the directions below:
• DO NOT disassemble or attempt to repair this monitor or other
components. This may cause an inaccurate reading.
8.2 Storage
Keep your monitor and other components in the storage case when not in
use.
Store your monitor and other components in a clean, safe location.
1. Remove the arm cuff from the monitor.
• To unplug the air plug, pull on the plastic air plug at the base of the tube,
not the tube itself.
2. Gently fold the air tube into the arm
cuff.
•Do not bend or crease the air tube
excessively.
3. Place your monitor and other components in
the storage case.
Do not store your monitor and other components:
8.3 Cleaning
• Do not use any abrasive or volatile cleaners.
• Use a soft dry cloth or a soft cloth moistened with mild (neutral) detergent
to clean your monitor and arm cuff and then wipe them with a dry cloth.
• Do not wash or immerse your monitor and arm cuff or other components
in water.
• Do not use gasoline, thinners or similar solvents to clean your monitor
and arm cuff or other components.
8.4 Disposal
Dispose of your monitor, other components and optional accessories
according to applicable local regulations.
Unlawful disposal may cause environmental pollution.
• Do not throw the air plug away. The air plug can be applicable to the
optional cuff.
For further information, visit our website at OmronHealthcare.com
Using the AC Adapter (optional accessory)
• Make sure not to place your monitor in a location where it is difficult to
plug and unplug the AC adapter.
• We recommend keeping batteries in your monitor at all times, even if you
choose to use the AC adapter. If only the AC adapter is used without
keeping batteries in your monitor, you may need to reset the date and
time each time you unplug and plug back the AC adapter. The readings
will not be deleted.
1. Insert the AC adapter plug into
the AC adapter jack on the rear
side of your monitor.
2. Plug the AC adapter into an
electrical outlet.
To unplug the AC adapter, unplug
the AC adapter from the electrical
outlet and then remove the AC adapter plug from the monitor.
• ONLY use the AC adapter, arm cuff, batteries and accessories specified
for this monitor. Use of unsupported AC adapters, arm cuffs and
batteries may damage and/or may be hazardous to this monitor.
8. Maintenance
• Changes or modifications not approved by the manufacturer will void
the user warranty.
•If your monitor and other components are wet.
•In locations exposed to extreme temperatures, humidity, direct
sunlight, dust or corrosive vapors such as bleach.
•In locations exposed to vibrations or shocks.
9. Optional Accessories
Easy Wrap ComFit Cuff AC Adapter
Arm circumference
9" - 17" (22 - 42 cm)
Model: HEM-FL31-B HEM-FL31-BZ
Model: HEM-ADPTW5
• These specifications are subject to change without notice.
• This monitor complies with the requirements of ISO 81060-2:2013. In the
clinical validation study, K5 was used on 85 subjects for determination of
diastolic blood pressure.
• This monitor has not been validated for use on pregnant patients.
• IP classification is degrees of protection provided by enclosures in
accordance with IEC 60529. This monitor and optional AC adapter are
protected against solid foreign objects of 0.5 inch (12.5 mm) diameter
and greater such as a finger. The optional AC adapter is protected
against vertically falling water drops which may cause issues during a
normal operation.
Pictogram on the Product
10. Specifications
Model
BP5250 HEM-7151T-Z
Display LCD digital display
Cuff pressure range 0 to 299 mmHg
Blood pressure
measurement range
SYS: 60 to 260 mmHg
DIA: 40 to 215 mmHg
Pulse measurement
range
40 to 180 beats / min.
Accuracy
Pressure: ±3 mmHg
Pulse: ±5 % of display reading
Inflation Automatic by electric pump
Deflation Automatic pressure release valve
Measurement method Oscillometric method
Transmission method
Bluetooth
®
Low Energy
Wireless
communication
Frequency range: 2.4 GHz (2400 - 2483.5 MHz)
Modulation: GFSK
Effective radiated power: < 20 dBm
Operation mode Continuous operation
IP classification
Monitor: IP20
Optional AC adapter: IP21
Rating DC6 V 4.0 W
Power source
4 “AA” batteries 1.5 V or optional AC adapter
(INPUT AC100 - 240 V 50 - 60 Hz
0.12 - 0.065 A)
Battery life
Approximately 1,000 measurements (using new
alkaline batteries)
Durable period (Service
life)
Monitor: 5 years
Arm cuff: 5 years
Optional AC adapter: 5 years
Operating conditions
+50 °F to +104 °F (+10 °C to +40 °C) / 15 to
90 % RH (non-condensing) / 800 to 1060 hPa
Storage / Transport
conditions
-4 °F to +140 °F (-20 °C to +60 °C) / 10 to 90 %
RH (non-condensing)
Weight
Monitor: Approximately 12 oz. (340 g) not
including batteries
Arm cuff: Approximately 5.8 oz. (163 g)
Dimensions
Monitor: Approximately 4.2" (w) × 3.4" (h) × 5.7"
(l) (105 mm × 85 mm × 145 mm)
Arm cuff: Approximately 5.7" × 20.9" (air tube:
29.5") (145 mm × 532 mm (air tube: 750 mm))
Cuff circumference
applicable to the
monitor
9" to 17" (220 to 420 mm)
Memory Stores up to 80 readings
Contents
Monitor, Easy Wrap ComFit Cuff, 4 “AA”
batteries, storage case, instruction manual,
quick start guide
Protection against
electric shock
Internally powered ME equipment (When using
only batteries)
Class II ME equipment (Optional AC adapter)
Applied part Type BF (arm cuff)
About a wireless communication interference
This product operates in an unlicensed ISM band at 2.4 GHz. In the event
this product is used near other wireless devices such as microwave and
wireless LAN, which operate on the same frequency band as this product,
there is a possibility that interference may occur.
If interference occurs, stop the operation of the other devices or relocate
this product away from other wireless devices before attempting to use it.
or
Types of marks used to indicate the correct positioning
of the artery for the upper arm
Identifies the type of cuff that is compatible with the
blood pressure monitor
FCC CAUTION
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This device complies with part 15 of FCC Rules and Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation
is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
• This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
This equipment complies with FCC/ISED radiation exposure limits set forth
for an uncontrolled environment and meets the FCC radio frequency (RF)
Exposure Guidelines and RSS-102 of the ISED radio frequency (RF)
Exposure rules as this equipment has very low levels of RF energy.
Your BP5250 Blood Pressure Monitor, excluding the arm cuff and batteries
is warranted to be free from defects in materials and workmanship
appearing within 3 years from the date of purchase, when used in
accordance with the instructions provided with the monitor. The arm cuff is
warranted to be free from defects in materials and workmanship appearing
within 1 year from the date of purchase when the monitor is used in
accordance with the instructions provided with the monitor. The above
warranty extends only to the original retail purchaser.
We will, at our option, replace without charge any monitor or arm cuff
covered by the above warranty. Replacement is our only responsibility and
your only remedy under the above warranty.
To obtain warranty service contact Customer Service by calling
1-800-634-4350 for the address of the inspection center and the return
shipping and handling fee that may apply.
Enclose the original printed receipt. Include a letter, with your name,
address, phone number, and description of the specific problem. Pack the
product carefully to prevent damage in transit. Because of possible loss in
transit, we recommend insuring the product with return receipt requested.
THE FOREGOING IS THE SOLE WARRANTY PROVIDED BY OMRON
IN CONNECTION WITH THIS PRODUCT, AND OMRON HEREBY
DISCLAIMS ANY OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. IMPLIED WARRANTIES
AND OTHER TERMS THAT MAY BE IMPOSED BY LAW, IF ANY, ARE
LIMITED IN DURATION TO THE PERIOD OF THE ABOVE EXPRESS
WARRANTY.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
OMRON SHALL NOT BE LIABLE FOR LOSS OF USE OR ANY OTHER
SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT COSTS,
EXPENSES OR DAMAGES.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
This warranty provides you with specific legal rights, and you may have
other rights that vary by jurisdiction. Because of special local
requirements, some of the above limitations and exclusions may not apply
to you.
OMRON
Battery-operated / AC Adapter-operated Blood Pressure Monitor
Information for Accompanying Documents in the Scope of IEC60601-1-
2:2014
Important information regarding Electromagnetic Compatibility
(EMC)
11. FCC/ISED Statement
• Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
12. Limited Warranty
FOR CUSTOMER SERVICE
Visit our web site at:
For USA - OmronHealthcare.com
For Canada - OmronHealthcare.ca
Call toll free: 1-800-634-4350
13. Guidance and Manufacturer’s Declaration
BP5250 conforms to IEC60601-1-2:2014 Electromagnetic Compatibility (EMC)
standard.
Further documentation in accordance with this EMC standard is available at
OmronHealthcare.com/emc. Refer to the EMC information for BP5250 on the website.
The Bluetooth
®
word mark and logos are registered trademarks owned by the
Bluetooth SIG, Inc. and any use of such marks by OMRON HEALTHCARE Co.,
Ltd. is under license. Other trademarks and trade names are those of their
respective owners.
pp Store and App Store logo are service marks of Apple Inc., registered in the
U.S and other countries.
Google Play and the Google Play logo are trademarks of Google LLC.
OMRON HEALTHCARE Co., Ltd
53, Kunotsubo, Terado-cho, Muko, Kyoto, 617-0002 JAPAN
Distributed by:
OMRON HEALTHCARE, INC.
1925 West Field Court, Lake Forest, IL 60045 U.S.A.
For USA - OmronHealthcare.com
For Canada - OmronHealthcare.ca
© 2019 OMRON HEALTHCARE, INC.
Made in Vietnam
To Next Page
Loading...
Need help?
General
