Omron C200HG-CPU43 Replacement Guide

7
< CPU Rack >
Unit name
C200H-series Unit
CJ-series Unit
Description
Communications Board
C200HW-COM01
Unnecessary
It is not necessary to mount the
communication unit for networks such as
SYSMAC LINK and SYSMAC NET.
C200HW-COM02(-V1)
CJ1W-SCU21-V1
The CJ Series does not have an inner-board
type communications unit. Use the unit type.
C200HW-COM03(-V1)
CJ1W-SCU41-V1
C200HW-COM04(-V1)
CJ1W-SCU21-V1
C200HW-COM05(-V1)
CJ1W-SCU21-V1
C200HW-COM06(-V1)
CJ1W-SCU41-V1
Insulation Plate for
CPU Backplane
C200H-ATT31
C200H-ATT51
C200H-ATT81
C200H-ATTA1
Unnecessary
The CJ-series CPU Backplane has an
installation structure to be insulated from the
control panel. The Insulation Plate for CPU
Backplane is not required.
I/O Control Unit
Unnecessary
CJ1W-IC101
Required to connect a CJ-series Expansion
Rack to a CJ-series CPU Rack.
< Expansion Rack >
Unit name
C200H-series Unit
CJ-series Unit
Description
Power Supply Unit
C200HW-PA□□□
CJ1W-PA202
(AC Power Supply Unit)
CJ1W-PA205C
(AC Power Supply Unit)
With replacement notification function.
CJ1W-PA205R
(AC Power Supply Unit)
The RUN output does not operate.
C200HW-PD□□□
CJ1W-PD022
(DC Power Supply Unit,
non-insulated type)
CJ1W-PD025
(DC Power Supply Unit)
Backplane
(Expansion Backplane)
C200HW-BI031
C200HW-BI051
C200HW-BI081-V1
C200HW-BI101-V1
Unnecessary
[DIN Track]
PFP-50N
PFP-100N
PFP-100N2
CJ-series Units are installed on the DIN
Track. The Backplane is not required.
I/O Interface Unit
Unnecessary
CJ1W-II101
Required for each CJ-series Expansion
Rack.
I/O Connecting Cable
C200H-CN311 (0.3 m)
C200H-CN711 (0.7 m)
C200H-CN221 (2 m)
C200H-CN521 (5 m)
C200H-CN131 (10 m)
CS1W-CN313 (0.3 m)
CS1W-CN713 (0.7 m)
CS1W-CN223 (2 m)
CS1W-CN323 (3 m)
CS1W-CN523 (5 m)
CS1W-CN133 (10 m)
CS1W-CN133-B2 (12 m)
Connects an I/O Control Unit to an I/O
Interface Unit or connects an I/O Interface
Unit to another I/O Interface Unit.
Backplane Insulation
Plate
C200HW-ATT32
C200HW-ATT52
C200HW-ATT82
C200HW-ATTA2
Unnecessary
*The CJ-series Backplane has an installation
structure to be insulated from the control
panel. The Insulation Plate for Backplane is
not required.
