Omron C200HG-CPU43 Replacement Guide

21
Appendix E. Table of Input/Output Units
■ Input Unit
(1) The terminal block of the CJ-series Unit differs from that of the C200H-series Unit. Change the wiring.
(2) If a different type of connector is used, change the wiring.
(3) If the input specifications differ, make sure that the system operates correctly.
(4) If the number of circuits increases, rewire the terminals to each common terminal.
(5) If internal current consumption is different, make sure the power supply capacity is large enough.
(6) Refer to the related manuals for details. Although CJ-series Units have basic functions of C200H-series Units,
some specifications may differ.
< DC Input Units >
C200H -series Unit
Corresponding CJ-series Unit
Description
Difference
C200H-ID211
CJ1W-ID211
DC Input Unit with terminal
block for 8 inputs.
Replace this unit with a DC
Input Unit with 16 inputs.
1) Terminal block
2) Input points (8 points → 16 points)
3) Input circuit specifications
Input impedance (2 kΩ → 3.3 kΩ)
ON voltage (10.2 VDC → 14.4 VDC)
OFF voltage (3 VDC → 5 VDC)
4) Internal current consumption
(5 VDC: 10 mA → 80 mA)
12 to 24 VDC, 10 mA, Terminal
block, 8 inputs
24 VDC, 7 mA, Terminal block,
16 inputs
C200H-ID212
CJ1W-ID211
DC Input Unit with terminal
block for 16 inputs.
1) Terminal block
2) Input circuit specification
Input impedance (3 kΩ → 3.3 kΩ)
3) Internal current consumption
(5 VDC: 10 mA → 80 mA)
24 VDC, 7 mA, Terminal block,
16 inputs
24 VDC, 7 mA, Terminal block,
16 inputs
C200H-ID215
CJ1W-ID231
DC Input Unit with connector
for 32 inputs.
1) Connector
Use the XW2Z-S010 Conversion Cable to
reuse the connecting cable.
2) No. of circuits (8 points/common x 4 circuits
→ 16 points/common x 2 circuits)
3) Input circuit specification
ON voltage(14.4 VDC → 19 VDC)
4) Internal current consumption
(5 VDC: 130 mA → 90 mA)
24 VDC, 4.1 mA, Connector,
32 inputs (Special I/O)
24 VDC, 4.1 mA,
Connector, 32 inputs
C200H-ID216
CJ1W-ID231
DC Input Unit with connector
for 32 inputs.
1) No. of circuits (32 points/common x 1 circuit
→ 16 points/common x 2 circuits)
2) Input circuit specification
ON voltage (14.4 VDC → 15.4 VDC)
3) Internal current consumption
(5 VDC: 100 mA → 90 mA)
24 VDC, 4.1 mA, Connector,
32 inputs (Group-2)
24 VDC, 4.1 mA,
Connector, 32 inputs
C200H-ID218
CJ1W-ID231
DC Input Unit with connector
for 32 inputs.
1) No. of circuits (32 points/common x 1 circuit
→ 16 points/common x 2 circuits)
2) Internal current consumption
(5 VDC: 100 mA → 90 mA)
24 VDC, 6 mA, Connector,
32 inputs (Group-2)
24 VDC, 4.1 mA,
Connector, 32 inputs
C200H-ID111
CJ1W-ID261
DC Input Unit with connector
for 64 inputs.
1) No. of circuits (32 points/common x 2 circuits
→ 16 points/common x 4 circuits)
2) Input circuit specifications
Input voltage (12 VDC → 24 VDC)
Input impedance (2.7 kΩ → 5.6 kΩ)
ON voltage (8 VDC → 19 VDC)
OFF voltage (3 VDC → 5 VDC)
3) Internal current consumption
(5 VDC: 120 mA → 90 mA)
12 VDC, 4.1 mA, Connector,
64 inputs (Group-2)
24 VDC, 4.1 mA,
Connector, 64 inputs
C200H-ID217
CJ1W-ID261
DC Input Unit with connector
for 64 inputs.
1) No. of circuits (32 points/common x 2 circuits
→ 16 points/common x 4 circuits)
2) Input circuit specification
ON voltage (14.4 VDC → 19 VDC)
3) Internal current consumption
(5 VDC: 120 mA → 90 mA)
24 VDC, 4.1 mA, Connector,
64 inputs (Group-2)
24 VDC, 4.1 mA,
Connector, 64 inputs
C200H-ID219
CJ1W-ID261
DC Input Unit with connector
for 64 inputs.
1) No. of circuits (32 points/common x 2 circuits
→ 16 points/common x 4 circuits)
2) Input circuit specifications
Input impedance (3.9 kΩ → 5.6 kΩ)
ON voltage (15.4 VDC → 19 VDC)
3) Internal current consumption
(5 VDC: 120 mA → 90 mA)
24 VDC, 6 mA, Connector,
64 inputs (Group-2)
24 VDC, 4.1 mA,
Connector, 64 inputs
