20
Appendix B. Change of unit area allocation
This section describes the differences in unit area allocation between C200HX/HG/HE and CJ2.
Refer to related manuals for details.
Item
C200HX/HG/HE
CJ2
Description
I/O allocation
Basic I/O
"Free location and fixed word allocation"
"Free location and free word allocation"
Change the word and bit addresses
used in the program.
I/O allocation
Special I/O
IR 100 to IR 199
IR 400 to IR 459
(10 words allocated for each Unit No.)
DM 1000 to DM 2599
(100 words allocated for each Unit No.)
CIO 2000 to CIO 2199
(10 words allocated for each Unit No.)
D20000 to D21999
(100 words allocated for each Unit No.)
Change the word and bit addresses
used in the program.
Refer to the
CJ2H-CPU6-EIP/CJ2H-CPU
6
□/CJ2M-CPU□□
SYSMAC CJ SERIES CJ2
CPU UNIT SOFTWARE
USER'S MANUAL (Cat. No.
W473) for details on I/O
allocation.
I/O allocation
Group-2
High-density I/O
IR 030 to IR 049
IR 330 to IR 341
(2 or 4 words allocated for each I/O
word)
The allocation is decided in the same
way as Basic I/O Units depending on
the installed position (rack and slot).
Change the word and bit addresses
used in the program.
Link Relay Area (LR)
LR 00 to LR 63
None
PC Link cannot be used with
CJ2.
Special Relay Area
(SR)
Auxiliary Relay Area
(AR)
SR 236 to SR 255
SR 256 to SR 299
AR 00 to AR 27
(1) Auxiliary Area and bits
Change the word and bit addresses
used in the program.
(2) Condition flags and clock pulses
Change the arithmetic flags in the
program to the condition flags. Clock
pulses are specified using global
symbols, such as "P_0.1ms" and
"P_1ms".
In CJ2, operation flags and
condition flags are specified
by labels.
PLC Link Words
SR 247 to SR 250
(In SR Area)
None
PC Link cannot be used with
CJ2.
Optical I/O Unit and
I/Terminal Area
IR 200 to IR 231
None
The Optical I/O Unit cannot
be used with CJ2.
DeviceNet Area and
SYSMAC BUS Area
IR 050 to IR 099
IR 350 to IR 399
[DeviceNet Area]
CIO 3200 to CIO 3799
[SYSMAC BUS Area]
None
SYSMAC BUS cannot be
used with CJ2.
Work/Internal I/O Area
IR 310 to IR 329
IR 342 to IR 349
IR 460 to IR 511
CIO 1200 to CIO 1499
CIO 3800 to CIO 6143
W000 to W511
Temporary Relay Area
(TR)
TR 00 to TR 07
TR 00 to TR 15
Holding Relay Area
(HR)
HR 00 to HR 99
HR 000 to HR 959
Error Log Area
DM 6000 to DM 6030
A100 to A199
Change the program if the
Error Log Area is read in the
program.
Appendix C. Change in PLC Settings
Item
C200HX/HG/HE
CJ2
Description
PLC Setup
Always uses the DM Area (DM 6600 to
DM 6655
Uses dedicated area for PLC settings
(there is no address for setting by
users).
Refer to related manuals for
details.
Appendix D. Change of execution timing etc.
Item
C200HX/HG/HE
CJ2
Description
Interrupt execution
method and execution
timing
Write interrupt programs in subroutines.
Write interrupt programs in interrupt
tasks.
In CJ2, interrupt tasks are
executed even when an
instruction is being executed
or I/O is being refreshed.
I/O table registration
Not required
Required
I/O tables must be created with the
CX-Programmer or other programming
device.
Cycle time
-
The cycle time is shortened with CS1.
If the system operation is affected by
cycle time, check the operation after
conversion.
To keep the same cycle time
as C200HX/HG/HE, set
Minimum Cycle Time in the
PLC Setup.
