Omron C200HG-CPU43 Replacement Guide

23
■ Output Unit
(1) The terminal block of the CJ-series Unit differs from that of the C200H-series Unit. Change the wiring.
(2) If a different type of connector is used, change the wiring.
(3) If the number of circuits increases, rewire the terminals to each common terminal.
(4) If the output specifications differ, make sure that the system operates correctly.
(5) The relay lifetime may vary depending on usage when a different relay is used. Refer to A-1-3 Precautions on
Contact Output Unit of the CJ2H-CPU6□-EIP/CJ2H-CPU6□/CJ2M-CPU□□ SYSMAC CJ Series CJ2 CPU Unit
Hardware USER'S MANUAL (Cat. No. W472) for details.
(6) If internal current consumption is different, make sure the power supply capacity is large enough.
(7) If the voltage and current consumption of the external power supply differ, make sure the power supply
capacity is large enough.
(8) Refer to the related manuals for details. Although CJ-series Units have basic functions of C200H-series Units,
some specifications may differ.
< Relay Output Units >
C200H-series Unit
Corresponding CJ-series Unit
Description
Difference
C200H-OC223
CJ1W-OC201
Relay Output Unit with
terminal block for 5 outputs
(independent contacts).
Replace this unit with a Relay
Output Unit with 8 outputs
(independent contacts).
1) Terminal block
2) Output points
(independent contacts 5 points → 8 points)
3) Output circuit specifications
ON/OFF response time (10 ms → 15 ms)
Used relay
4) Internal current consumption
(5 VDC: 10 mA → 90 mA,
26 VDC: 46 mA → 24 VDC: 48 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 5 outputs
(independent contacts)
250 VAC/24 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
C200H-OC224
CJ1W-OC201
Relay Output Unit with
terminal block for 8 outputs
(independent contacts).
1) Terminal block
2) Output circuit specifications
ON/OFF response time (10 ms → 15 ms)
Used relay
3) Internal current consumption
(5 VDC: 10 mA → 90 mA,
26 VDC: 75 mA → 24 VDC: 48 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
250 VAC/24 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
C200H-OC224V, OC224N
CJ1W-OC201
Relay Output Unit with
terminal block for 8 outputs
(independent contacts).
1) Terminal block
2) Output circuit specification
Used relay
3) Internal current consumption
(5 VDC: 10 mA → 90 mA,
26 VDC: 90 mA → 24 VDC: 48 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
250 VAC/24 VDC, 2 A,
Terminal block, 8 outputs
(independent contacts)
C200H-OC221
CJ1W-OC211
Relay Output Unit with
terminal block for 8 outputs.
Replace this unit with a Relay
Output Unit with 16 outputs.
1) Terminal block
2) Output points (8 points → 16 points)
3) Output circuit specifications
ON/OFF response time (10 ms → 15 ms)
Used relay
4) Internal current consumption
(5 VDC: 10 mA → 110 mA,
26 VDC: 75 mA → 24 VDC: 96 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 8 outputs
250 VAC/24 VDC, 2 A,
Terminal block, 16 outputs
C200H-OC222
CJ1W-OC211
Relay Output Unit with
terminal block for 12 outputs.
Replace this unit with a Relay
Output Unit with 16 outputs.
1) Terminal block
2) Output points (12 points → 16 points)
3) No. of circuits (12 points/common x 1 circuit
→ 8 points/common x 2 circuits)
4) Output circuit specifications
ON/OFF response time (10 ms → 15 ms)
Used relay
5) Internal current consumption
(5 VDC: 10 mA → 110 mA,
26 VDC: 75 mA → 24 VDC: 96 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 12 outputs
250 VAC/24 VDC, 2 A,
Terminal block, 16 outputs
C200H-OC222V, OC222N
CJ1W-OC211
Relay Output Unit with
terminal block for 12 outputs.
Replace this unit with a Relay
Output Unit with 16 outputs.
1) Terminal block
2) Output points (12 points → 16 points)
3) No. of circuits (12 points/common x 1 circuit
→ 8 points/common x 2 circuits)
4) Output circuit specification
Used relay
5) Internal current consumption
(5 VDC: 10 mA → 110 mA,
26 VDC: 90 mA → 24 VDC: 96 mA)
250 VAC/24 VDC, 2 A,
Terminal block, 12 outputs
250 VAC/24 VDC, 2 A,
Terminal block, 16 outputs
