I/O Memory Allocation Section 9-3
210
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A344 All EM File
Memory
Starting
Bank
Contains the starting bank num-
ber of EM file memory (bank
number of the first formatted
bank). All EM banks from this
starting bank to the last bank in
EM are formatted for use as file
memory.
0000 to
000C Hex
Bank 0 to C
Same as
CS/CJ-series
PLC.
A346
and
A347
All Number of
Remaining
Words to
Transfer
These words contain the 8-digit
hexadecimal number of words
remaining to be transferred by
FREAD(700) or FWRIT(701).
When one of these instructions is
executed, the number of words to
be transferred is written to A346
and A347.
While the data is being trans-
ferred, the value in these words
is decremented each time that
1,024 words are transferred.
Data re-
maining in
transfer
(1,024
word, or 1-
KW units)
Not used.
All These words contain the CPU
Unit’s internal clock data in BCD.
The clock can be set from a Pro-
gramming Device such as a Pro-
gramming Console, with the
DATE(735) instruction, or with a
FINS command (CLOCK
WRITE,0702).
A35100
to
A35107
Seconds (00 to 59) (BCD)
A35108
to
A35115
Minutes (00 to 59) (BCD)
A35200
to
A35207
Hours (00 to 23) (BCD)
A35208
to
A35215
Day of the month (01 to 31)
(BCD)
A35300
to
A35307
Month (01 to 12) (BCD)
A35308
to
A35315
Year (00 to 99) (BCD)
A351 to
A354
A35400
to
A35407
Calen-
dar/Clock
Area
Day of the week
(00 to 06) (BCD)
00: Sunday, 01: Monday, 02:
Tuesday,
03: Wednesday, 04: Thursday,
05: Friday, 06: Saturday
Switches be-
tween Virtual
Clock and
Computer
Clock de-
pending on the
Cycle Time
Mode.
Same as
CS/CJ-
series
PLC.
A355 A35500
to
A35915
Inner Board
Monitoring
Area
The function of these words is
defined by the Inner Board.
Not used.
