I/O Memory Allocation Section 9-3
211
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A360 to
A391
A36001
to
A39115
Executed
FAL Num-
ber Flags
The flag corresponding to the
specified FAL number will be
turned ON when FAL(006) is
executed. Bits A36001 to A39115
correspond to FAL numbers 001
to 511.
The flag will be turned OFF when
the error is cleared.
1: That FAL
was exe-
cuted
0: That FAL
wasn’t exe-
cuted
Same as
CS/CJ-series
PLC.
A38506 The system deleted the remain-
der of an EM file memory file that
was being updated when a power
interruption occurred.
1: File de-
leted
0: No files
deleted
Not used.A385
A38507
File Deleted
Flags
The system deleted the remain-
der of a Memory Card file that
was being updated when a power
interruption occurred.
1: File de-
leted
0: No files
deleted
Not used.
A39204 RS-232C
Port Error
Flag
ON when an error has occurred
at the RS-232C port. (Not valid in
peripheral bus mode or NT Link
mode.)
1: Error
0: No error
Same as
CS/CJ-series
PLC.
A39205 RS-232C
Port Send
Ready Flag
(No- proto-
col mode)
ON when the RS-232C port is
able to send data in no-protocol
mode.
1: Able-to-
send
0: Unable-
to-send
Same as
CS/CJ-series
PLC.
A39206 RS-232C
Port Re-
ception
Completed
Flag
(No-
protocol-
mode)
ON when the RS-232C port has
completed the reception in no-
protocol mode.
· When the number of bytes was
specified: ON when the specified
number of bytes is received.
· When the end code was speci-
fied: ON when the end code is
received or 256 bytes are re-
ceived.
1: Recep-
tion com-
pleted
0: Recep-
tion not
completed
Same as
CS/CJ-series
PLC.
A392
A39207 RS-232C
Port Re-
ception
Overflow
Flag
(No-
protocol
mode)
ON when a data overflow oc-
curred during reception through
the RS-232C port in no-protocol
mode.
· When the number of bytes was
specified: ON when more data is
received after the reception was
completed but before RXD(235)
was executed.
· When the end code was speci-
fied: ON when more data is re-
ceived after the end code was
received but before RXD(235)
was executed. ON when 257
bytes are received before the end
code.
1: Overflow
0: No over-
flow
Same as
CS/CJ-series
PLC.
