9
EN
6. Put the inhalation top back onto the medication tank.
1) Lower the inhalation top on the medication tank.
2) Rotate the inhalation top clockwise.
Using the mouthpiece
7a. Assemble the mouthpiece.
Make sure that the valves are properly
attached.
Refer to this drawing.
7b. Attach the mouthpiece to the
nebulizer kit and press the cap
onto the inhalation top.
7c. Keep the mouthpiece in the
mouth during both inhalation
and exhalation in order to get
the maximal benefit by the valve
system.
Note: Infants or any patients who have particular
needs should use the mask instead of the
mouthpiece. When using a mask, make sure
the cap is removed from the inhalation top.
Caution:
In order to remove the mouthpiece from the nebulizer kit, it
is important to detach first the cap from the inhalation top
and then pull it out. Do not reverse this sequence!
1
2
1
2
