Cycle Time Read Section 6-2
Key Functions
:Moves the cursor to the right.
:Moves the cursor to the left.
to : Input numeric values.
4. Press the WRITE Key when the time and date have been set.
5. Press the CLR Key to exit.
6-2 Cycle Time Read
This operation is used to display the average cycle time for all programs (the
total of all tasks) that are being executed.
Key Sequence
Operation Example
1,2,3... 1. From the initial display, access the cycle time display.
…
CHG
14:25:58 FRI(5)
Last 2 digits of A.D.
calendar year:
00 to 99.
Months: 01 to 12
Days: 01 to 31
Hour
00 to 23
Minutes
00 to 59
Seconds
00 to 59
Days
Sun to Sat (0 to 6)
CHG TIM?98-04-03
↓
↑
0
9
WRITE
TIM 98-04-03
14:25:58 FRI(5)
RUN MONITOR PROGRAM
OK OK No
MON
Initial display
MON
CLR
000000 CT00
MON
000000CYCLE TIM
112.1MS
Average cycle time for all programs.
Refreshed in real-time.
