Omron CJ2 - Page 14

CJ2
Modular PLC
14
Dimensions
CJ2M-CPU1_
CJ2M-CPU3_
2.7
2.7
76.2
90
31
75
84.5
76.2
62
2.7
2.7
90
84.5
75
