CJ-Series analog I/O and control units
Modular PLC
20
Note: All Analogue I/O units are designated as Special I/O units, except TS561/TS562, which are Basic I/O units (cannot be used with CP1H).
Accessories
2 Thermocouple
input
B, E, J, K, L, N, R, S,
T, U,
WRe5-26, PLII,
-100 to 100 mV
1/64,000 0.05% 5 ms/point 31 mm Configurable alarms, maintenance functions M3 CJ1W-PTS15
2 Resistance ther-
mometer input
Pt50, Pt100, JPt100,
Ni508.4
1/64,000 0.05% 5 ms/point 31 mm Configurable alarms, maintenance functions M3 CJ1W-PTS16
4 Thermocouple
Input
B, J, K, L,
R, S, T
0.1°C 0.3% 62.5 ms/point 31 mm 4 configurable alarm outputs M3 CJ1W-PTS51
4 Resistance ther-
mometer input
Pt100, JPt100 0.1°C 0.3% 62.5 ms/point 31 mm 4 configurable alarm outputs M3 CJ1W-PTS52
6 Thermocouple
input
K-type
(-200 to
1,300°C)
J-Type
(-100 to 850°C)
0.1°C 0.5% 40 ms/point 31 mm Basic I/O unit, setup by DIPswitches,
adjustable filtering 10/50/60 Hz
M3 CJ1W-TS561
Screwless CJ1W-TS561 (SL)
6 Resistance ther-
mometer input
Pt100
(-200 to 650°C)
Pt1000
(-200 to 650°C)
0.1°C 0.5% 40 ms/point 31 mm Basic I/O unit, setup by DIPswitches,
adjustable filtering 10/50/60 Hz
M3 CJ1W-TS562
Screwless CJ1W-TS562 (SL)
4 Temperature con-
trol loops, Thermo-
couple
B, J, K, L,
R, S, T
0.1°C 0.3% 500 ms total 31 mm 4 control outputs: PNP open
collector, 100 mA max.
M3 CJ1W-TC002
2 Temperature con-
trol loops, Thermo-
couple
B, J, K, L,
R, S, T
0.1°C 0.3% 500 ms total 31 mm 2 control outputs: PNP open
collector, 100 mA max., 2 current transform-
erinputs for heater burnout detection.
M3 CJ1W-TC004
4 Temperature con-
trol loops, RTD
Pt100, JPt100 0.1°C 0.3% 500 ms total 31 mm 4 control outputs: PNP open
collector, 100 mA max.
M3 CJ1W-TC102
2 Temperature con-
trol loops, RTD
Pt100, JPt100 0.1°C 0.3% 500 ms total 31 mm 2 control outputs: PNP open
collector, 100 mA max., 2 current transform-
erinputs for heater burnout detection.
M3 CJ1W-TC104
*1
Accuracy for Voltage and Current Inputs/Outputs as percentage of full scale and typical value at 25°C ambient temperature (Consult the operation manual for details)
Accuracy for Temperature Inputs/Outputs as percentage of process value and typical value at 25°C ambient temperature (Consult the operation manual for details)
Description Connection
type
Order code
Replacement 18-point screwless terminal blocks for I/O units, pack of 5 pcs. Screwless CJ-WM01-18P-5
Replacement 18-point screw terminal blocks for I/O units, pack of 5 pcs. M3 CJ-OD507-18P-5
Points Type Ranges Resolution Accuracy
*1
Conversion
time
Width Remarks Connection
type
Order code
