Omron CJ2M-CPU33 - Page 33

7
．
Serial Communications Connection Procedure
30
10
Click Compare in the View
Parameters Dialog Box.
11
Check that a message
"Compare successful" is
displayed in the dialog box on
the right. Click Close.
12
Click OK in the View
Parameters Dialog Box.
13
Select Exit from the File Menu
in the PLC IO Table Window to
close.
