Distributed Clock Setup
1
Setting Distributed Clocks (DC)
for Master
In the Master0 (Deactivated) tab
page, select Distributed Clocks
tab.
2
Select Master Shift (EtherCAT
Master Time controlled by
Reference Clock).
3
Setting Distributed Clock (DC)
for the Slave
In the Solution Explorer, select
the target slave and display the
Distributed Clock tab page.
