8.2. How to Check for Errors
Checking the EtherCAT Status
You can check the EtherCAT status from Diagnosis Mode of Power PMAC IDE.
Right-click on Master0 (Deactivated) under EtherCAT in the Solution Explorer, then select
Diagnosis Mode to open the Diagnosis Mode page.
