Dimensions
Technical Specifications
CM-S221
RED ABS HOUSING
Dimensions in mm and [inches
in brackets]
DC Switching
Contacts Arrangements: 2 x N/C + 1 x N/O
N/C Contact Rating 24Vdc / 0.3Amp Inductive/Resistive
N/C Contact Operating Distance 7mm ON / 12mm OFF
N/C Contact Close/Drop/Bounce 3ms / 2.1ms / 0.7ms
N/O Contact Rating 24Vdc / 0.3Amp Inductive/Resistive
N/O Contact Operating Distance 8mm OFF / 10mm ON
N/O Contact Close/Drop/Bounce 0.5ms / 0.3ms / 0.7ms
External Fuse (Customer Supplied) 0.2 Amp Fast Acting
IP Rating IP67
Vibration / Shock 50—100Hz / 10g
Operating Temperature -10 to +55C
Mounting & Fixture Target to Target
Connection Pre-wired
Red ABS Resin Filled Construction
