Omron CP1L Brochure

Features at a glance
• 4 high-speed encoder inputs and 2 high-speed pulse outputs
• CPUs with AC or DC supply and 14, 20, 30 or 40 I/O built-in
• Instruction set compatible with CP1H-, CJ1-, and CS1 series PLC
• Optional RS232C and RS-422A/485 serial ports
• USB programming port
• Scaleable with a wide range of I/O units
(maximum up to 160 I/O points)
• Motion functionality
• One and the same software as other Omron controllers
All you need in one series
With the CP1L series you get all the functionality and flexibility
you need in a controller plus the added advantage of one
single platform, which means no worries about field-buses
or integration of software. And the same ‘Smart Platform’
communication routing is provided over multiple network
layers. The CP1L series… the compact range that simply meets
your needs.
…take the lead today!

Omron CP1L Specifications

General

Model	CP1L
Data Memory Capacity	32K words
Program Capacity	10K steps
Communication Ports	USB, RS-232C
Expansion	I/O
Pulse Output	100 kHz
Built-in I/O	Digital I/O
Expansion Slots	Supports up to 3 expansion units
Operating Voltage	100-240 VAC or 24 VDC (varies by model)
Operating Temperature	55 degrees Celsius
Storage Temperature	75 degrees Celsius
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude
Shock Resistance	147 m/s^2, 3 times in X, Y, and Z directions
