Omron CPM1A

A--36
Micro Programmable Controller
CPM1A
D
i
m
e
n
s
i
o
n
s
Unit: mm (inch)
J CPU, EXPANSION I/O AND SPECIAL I/O MODULES
DC power supply
AC power supply
W
90
(3.54)
50 (1.97)
70 (3.35)
Model W
CPM1A-10CD
j
-A/D-V1
66 (2.60)
CPM1A-20CD
j
-A/D-V1
86 (3.39)
CPM1A-30CD
j
-A/D-V1
130 (5.12)
CPM1A-40CD
j
-A/D-V1
150 (5.91)
CPM1A-20ED
j
86 (3.39)
CPM1A-8E
j
66 (2.60)
CPM1A-SRT21 66 (2.60)
CPM1A-MAD01 66 (2.60)
CPM1A-TS
jjj
86 (3.39)
CPM1A-MAD11 86 (3.39)
CPM1A-DRT21 66 (2.60)
CPM1A-PRT21 66 (2.60)
Unit: mm (inch)
J COMMUNICATION ADAPTER MODULES
30 (1.18)
21
21
90
(3.54)
81
50
56 (2.20)
81
50
61 (2.40)
CPM1-CIF01 CPM1-CIF11
30 (1.18)
90
(3.54)
J DIMENSIONS WITH PERIPHERAL DEVICES ATTACHED
Approx. 90 (3.54
)
Approx. 110 (4.33
)
CPU with DC Power Supply CPU with AC Power Supply
