Omron CPM1A

A--42
Micro Programmable Controller
CPM1A
C
o
m
m
u
n
i
c
a
t
i
o
n
s
J NT LINK FOR PROGRAMMABLE TERMINALS
Use Omron’s high-speed NT Link for real-time communications between the CPM1A and a Programmable Terminal.
Operator Interface
Terminal
* Available in Canada only.
CBL-804*
CBL-803*
C200H-CN_0-EU,
NT31C-CN_0-EU,
(for NT31C Port B only)
J HOST LINK COMMUNICATIONS
CPM1A Host Link communications consist of interactive procedures whereby the CPM1A returns a response to a command sent from the
IBM PC/AT or compatible computer. These communications allow the IBM PC/AT or compatible computer to read and write in the
CPM1A’s I/O Areas and Data Memory Areas as well as in areas containing the status of various settings.
1:1 Host Link Communications
CPM1A-V1
CPU
RS-232C
Adapter
Response
Command
C200H-CN229-EU (2 m)
CBL-202*
* Available in Canada only.
