Omron CS1G-CPU42H Replacement Guide From C200H To Cs

8
< Memory Cassettes >
Unit name
C200H-series Unit
CS1-series Unit
Description
Memory Unit
RAM Unit
C200H-MR431
(Battery type)
C200H-MR432
(Capacitor type)
C200H-MR831
(Battery type)
C200H-MR832
(Capacitor type)
C200H-MR433
(Battery type, with clock
function)
C200H-MR833
(Battery type, with clock
function)
None
The CS1-series CPU Unit has a nonvolatile
memory for user program in it. The Memory
Unit is not required.
It also has the clock function.
EEPROM Unit
C200H-ME431
C200H-ME432
(with clock function)
C200H-ME831
C200H-ME832
(with clock function)
None
The CS1-series CPU Unit has a nonvolatile
memory for user program in it. The Memory
Unit is not required.
It also has the clock function.
The program file and the parameters are
stored in the memory card. It is possible to
execute operation by reading them when the
PLC is turned ON. (Automatic File Transfer
at Startup)
EPROM Unit
C200H-MP831
None
The CS1-series CPU Unit has a nonvolatile
memory for user program in it. The Memory
Unit is not required.
It also has the clock function.
The program file and the parameters are
stored in the memory card. It is possible to
execute operation by reading them when the
PLC is turned ON. (Automatic File Transfer
at Startup)
< Expansion Rack >
Unit name
C200H-series Unit
CS1-series Unit
Description
Power Supply Unit
C200H-PS221
C200HW-PA204
(AC Power Supply Unit)
C200HW-PA204C
(AC Power Supply Unit)
With replacement notification function.
C200HW-PA204S
(AC Power Supply Unit)
With 24 VDC service power supply.
C200HW-PA204R
(AC Power Supply Unit)
The RUN output does not operate.
C200HW-PA209R
(AC Power Supply Unit)
The RUN output does not operate.
C200H-PS211
C200HW-PD024
(DC Power Supply Unit)
C200HW-PD025
(DC Power Supply Unit)
Backplane
(Expansion Backplane)
C200H-BC031(-□□)
C200H-BC051(-□□)
C200H-BC081(-□□)
C200H-BC101(-□□)
CS1W-BI033/BI032
CS1W-BI053/BI052
CS1W-BI083/BI082
CS1W-BI103/BI102
Respectively for 3, 5, 8, and 10 slots
The mounting hole dimensions are the
same.
Connecting Cable for
Expansion Backplane
C200H-CN□□1
CS1W-CN□□3
Connects a CS1-series Expansion
Backplane to a CPU Backplane or another
CS1-series Expansion Backplane.
CS1W-CN□□1
Connects a C200HW-BI□□1-V2 Expansion
I/O Backplane to a CPU Backplane or
CS-series Expansion Backplane.
